Metro MET-1301T M3 TESA LVDT Air Display Unit

Brand: Metro
ID#: MET-1301T-AGG
|MFGID: MET-1301T
Your Price:
$1,408.75
Add Calibration w/ Certificate?
No
  • No
  • Yes - A2LA Calibration Digital Amplifier (+ $93.00)
Questions?CallCall Us864.433.9771|Mon-Fri 8-5 EST

Product Information

Description

Metro MET-1301T M3 TESA LVDT Air Display Unit with 2 inputs for TESA brand LVDT's. 4.3" color touch screen display. 2 inputs, 1 or 2 characteristics -Dynamic measurement (Max, Min, Max-Min, Average Median), 3 display modes (Needle horizontal bargraph, numerical value only), with or without tolerance,Control limits (warning, yellow colour). 1 or 2 characteristics displayed. Optionnal I-O module (Go-NoGo, preset, transfetr, start dynamic measurement....). Modbus RTU, sorting in classes (16 class max). Possibility to connezct other MBUS modules for mixing probes types on the same display (ex. air gage + inductive)

Specifications

  • Specifications:Resolution: .0001mm
    Accuracy .001mm
    IP 54
    4.3" Color Touchscreen
    Programmable in inch or metric
    USB power and-or data transmisison for the easiest keyboard emulation in the industry
    Very easy to program and use
